Product introduction
| Resin diamond cast disc | ||||||
| OD(outer diameter)(mm) | Thickness(mm) | Sand width(mm) | Working layer thickness(mm) | Hmesoporous(mm) | remarks |  |
| 150 | 10 | 50 | 3 | 12.7 |  | |
| 150 | 10 | 0 | 3 | 12.7 | Full sand | |
| 200 | 12 | 70 | 3 | 12.7 | ||
| 200 | 12 | 83 | 3 | 12.7 | ||
| 200 | 12 | 0 | 3 | 12.7 | Full sand | |
| Flexible resin diamond disk | ||
| OD(outer diameter)(nm) | Thickness(nm) | Hmesoporous(nm) |
| 150 | 10 | 25.4 |
| 200 | 10 | 25.4 |
  | ||
2. Production of raw materials
Imported resin is selected as binder, and imported diamond with high sharpness, high strength and high wear resistance is selected as abrasive.3. Process
The resin powder is mixed evenly with diamond particles and coated to the surface with a base.4. Product features
The outer operating layer is flexible and polished in a curved manner. Items that are not level have the property of not scratching items and providing seamless and efficient wear. Economical alternative to similar products imported from abroad.
5. Different from similar products on the market
1. High grinding efficiency and long service life; 2. High machining accuracy and small workpiece surface roughness; 3. Suitable for processing hard and brittle materials; 4. Less dust, less environmental pollution6. Applied range
It is mainly used for the unique processing of hard and brittle substances, such as jade, crystal, glass, artificial crystal, ceramics, and the process of grinding and polishing from coarse to fine grain using grinding wheels.
